Bioss Biotechnology
in combination with the analyzer there are now 60 CE marked tests in the Bioss produce portfolio to offer a comprehensive range of high quality clinical chemistry reagents, calibrators and controls which meet the needs of today's growing laboratories.
The new tests include substrates, enzymes, electrolytes, lipids, specific proteins and special tests.
All reagents have been specifically designed with the Bioss automated analyzers in mind, so the combination of analyzer and reagents allows customers to enjoy features and benefits that are only normally possible on high cost Clinical Chemistry systems.
â— Bench top, Discrete, random access, fully automated;
â— Constant speed 200 tests per hour;
â— Unique Self-lubricating lead rail, accurate positioning and low noise
â— Refrigerated reagent compartment with 45 reagent positions;
â— 120 reusable cuvettes with 7-step auto wash;
â— Automatic probe cleaning, liquid level detection & collision protection
â— Reversed optic system with 8 wavelengths: 340~700nm (2 optional)
â— Automatic dilution for abnormal sample
â— External bar code reader (optional)
â— Bi-directional LIS interface
â— Multi-language available
THROUGHPUT:
Throughput: Up to 300 photometric tests/hour for standalone unit and single analytical unit of modular system, up to 480 tests/hour for with optional ISE module.
Sample Handling:
Sample tray: 95(5 rocks x 19 positions).
Primary tube (length up to 100mm)
Pediatric vial
Sample volume: 2~100 μL/test (in increments of 1μL.
Pipetting Arm:
One pipetting arm for sample and reagent, including reaction preheater, probe collision sensor, capacitive level sensor and reaction mixer.
Probe cleaning :
Internal and External.
Reagent Handling: :
Reagent tray: Up to 72 single reagents.
Multiple vials per test
Refrigerated compartment at 8˚C ± 1˚C.
Pipetting Arm:
One pipetting arm for sample and reagent, including reaction preheater, probe collision sensor, capacitive level sensor and reaction mixer.
Probe cleaning :
Internal and External.
External Bar Code Reader (optional):Used for sample and reagent programming;Applicable to various bar code systems including Codabar, ITF (Interleaved Two ofFive), Code128, Code39, UPC/EAN, Code93; Capable to communicate with LIS in a bi-directional mode
Reaction System: :
Reaction volume: 180~500 μL
Water consumption: 1.5L/hour(deionized)
Reaction cuvette: 80 re-usable plastic cuvettes, Optical length: 6mm.
Warm air incubator: 37ËšC.
Reaction time: 0 to 10min.
Washing station: 6 stages.
Operating temperature: 37 ÌŠC with 0.1 ÌŠC fluctuation
Optical System: :
Light source: Precision UV quartz Halogen lamp
Photometer: Reversed optics, grating photometry
Wavelength: 340nm, 380nm, 405nm, 450nm, 490nm, 505nm, 550nm, 590nm, 620nm, 650nm, 700nm, 750nm.
Absorbance range:-0.1~3 Abs
Photometry: single or double wavelength simultaneous reading.
ISE Module (Optional): :
Principle: Indirect K+, Na+ Cl-, with 22 μL sample aspiration
Control and Calibration: Calibration mode: Linear (one-point, two-point and multi-point), Logit-Log 4P, Logit-Log 5P, Spline, Exponential, Polynomial, Parabola
Control rules: Westgard multi-rule, Twin plot
Operation Unit: :
Operation system: Windows® XP Professional/Home SP2/ Windows® 7
or above Windows® 8
Power Requirements: 110/230 VAC, 50/60Hz, 550VA
Working Temperature: 18ËšC - 30ËšC
Humidity: 35~80% .
BiossBioTech
